Telic Protocol Tracking Devices: Technical Deployment Guide
Telic telematics devices like the SBC-AVL and Picotrack Endurance are professional-grade tools designed for extreme reliability in fleet and asset management. Using the dedicated 5067 port protocol, they ensure efficient data transmission even in low-coverage areas.
1. Technical Wiring Diagrams
Correct wiring is critical for device longevity and feature support (CAN Bus, Ignition, etc.).
SBC3 CAN / SBC-AVL Pinout (6-Pin Connector)
| Pin No | Signal Name | Description |
|---|---|---|
| 1 | VCC (Power) | 7V – 32V DC External Power |
| 2 | GND | Ground |
| 3 | DIG_IN1 | Digital Input (Ignition detection) |
| 4 | DIG_IN2 | General Purpose Digital Input |
| 5 | CAN H | CAN Bus High (for engine data) |
| 6 | CAN L | CAN Bus Low |
2. SMS Configuration Commands
Telic devices can be configured remotely via SMS using specific syntax. Note: replace {6digitsIMEI} with the last 6 digits of your device IMEI.
Basic Configuration String
0011{6digitsIMEI},[APN],[User],[Pass],[ServerIP],[Port],…
Common Commands for Picotrack & SBC Series
| Function | SMS Command Syntax (Example) |
|---|---|
| Set Server & APN | 0011{IMEI},internet,user,pass,1.2.3.4,5067,0,1 |
| Set Time Interval | 0011{6digitsIMEI},,,,60,0,200000700000... (Sends every 60s) |
| Factory Reset | begine1aLdY (Specific to SBC3 variants) |
| Reboot Device | REBOOT={6digitsIMEI} |
3. Comparison: SBC vs. Picotrack Series
| Model | Target Asset | Battery Life | Protection |
|---|---|---|---|
| SBC-AVL 4G | Fleet Vehicles | Int. Backup Battery | Standard |
| SBC3 CAN | Heavy Trucks | 660 mAh / 4 Ah options | IP6K6K (Waterproof) |
| Picotrack Endurance | Containers/Wagons | Up to 9 Years (Primary) | IP69K (Extreme) |
Conclusion
Whether deploying the compact SBC-AVL for city fleets or the Picotrack Endurance Primary for global container tracking, adhering to the German engineering standards of Telic AG ensures data integrity and asset security.
