Skypatrol Protocol Tracking Devices: Features and Comparison
When it comes to reliable fleet management and asset tracking, the Skypatrol protocol (commonly using port 5021) is a industry standard. These devices are known for their durability and seamless integration with various GPS tracking platforms.
Comparison Table: Skypatrol Compatible Models
| Model Name | Manufacturer | Protocol Port | Best Use Case |
|---|---|---|---|
| TT8750 | Skypatrol | 5021 | Standard Vehicle Tracking |
| TT8750+ | Skypatrol | 5021 | Enhanced Fleet Management |
| TT9500 | Skypatrol | 5021 | High-Performance Logistics |
| TT9200 | Skypatrol | 5021 | Versatile Asset Security |
| TT8850 | Skypatrol | 5021 | Compact Location Services |
| GSM5108 | Skypatrol | 5021 | Legacy System Integration |
Why Choose Skypatrol?
Devices like the TT8750 and TT9500 offer a robust communication framework that ensures data accuracy and low latency. Whether you are managing a small delivery team or a large-scale logistics operation, these devices provide the stability needed for real-time monitoring.
Skypatrol Protocol Tracking Devices: Technical Specifications
The following technical specifications are for the most common Skypatrol tracking devices compatible with the 5021 protocol port. These devices utilize the EDDIE+ (Event Driven Dynamic Interface Engine) protocol, which is designed to optimize data consumption by up to 40%.
Skypatrol TT8750 & TT8750+
The Skypatrol TT8750 is a versatile vehicle tracker, while the TT8750+ (plus) serves as a high-performance upgrade with expanded I/O and geofencing capabilities.
- Communication: Quad-band GSM (850/900/1800/1900 MHz).
- GPS Sensitivity: Highly sensitive reception at -162dBm.
- Inputs/Outputs (I/O):
- TT8750: 3 digital inputs and 2 digital outputs.
- TT8750+: Up to 9 inputs and 5 outputs (with expansion option), including RS232 for fuel/temperature sensors.
- Battery: Internal Li-Polymer 250 mAh backup battery.
- Environmental: Splash-proof housing; operating temperature from -30°C to +80°C.
- Geofencing: The TT8750+ supports up to 250 circular geofences and advanced polygonal/route geofencing.
Skypatrol TT9500 (Defender)
Commonly referred to as the Skypatrol TT9500 Defender, this model is optimized for asset recovery and vehicle tracking in challenging environments.
- Network: GSM/GPRS Quad-band.
- GPS Receiver: Ultra-sensitive -162dBI for reliable positioning.
- Storage: Internal memory stores up to 3,000 messages when outside cellular coverage.
- Interfaces: Includes 2 digital inputs and a USB port for extra connectivity; no voice or CAN bus support.
- Dimensions: Compact build at 80mm x 50mm x 26mm, weighing 89g.
- Tracking Metrics: Supports monitoring for engine hours, mileage, and eco-driving habits.
Skypatrol TT9200
The Skypatrol TT9200 is a compact, economical tracking solution designed for discreet installation.
- Design: Ultra-compact size (63mm x 50mm x 13mm) and lightweight at 44g.
- Connectivity: Integrated antennas for internal installation; includes OBD II adapter (CBL075) support.
- Power: Low power consumption for energy efficiency; operates on vehicle power supply.
- I/O: 2 digital inputs and 2 digital outputs.
- Status Indication: Features LED lights to indicate GPS and cellular network status.
Skypatrol TT8850 & GSM5108
These models are primarily used for personal or legacy system integration.
- TT8850: Specialized personal tracker often using port 6079 (software dependent) for compact location services.
- GSM5108: A legacy fleet model typically configured on port 6021 (or 5021 for protocol compatibility).
