Xirgo XT-Series Technical Deployment Manual
Comprehensive reference for Port 5081 Protocol, Hardware Setup, and Error Resolution.
1. Device Comparison & Network Compatibility
| Model Series | Type | Connectivity | Best For… |
|---|---|---|---|
| XT-20xx / XT-3200 | OBD-II | 2G/3G/CDMA/LTE | Light Vehicles / Plug-and-Play |
| XT-21xx / XT-50xx | Fleet Wired | GSM / CDMA / LTE | Hidden installation in trucks/vans |
| XT-45xx / XT-47xx | Weatherproof | LTE / 3G / CDMA | Trailers & Outdoor Assets (IP67) |
| XT-48xx | Solar | LTE-M / NB-IoT | Energy harvesting for long-life assets |
| XT-62xx / ST7200 | Industrial | Global LTE | Global IoT / Multi-CANbus data |
2. Configuration & GPRS Commands
A. SMS Initialization
Send via SMS to the device SIM. Default password: bestpassword.
# Set APN and Server IP/Port (Port 5081)
bestpassword Wapn,apn.name,user,pass,0.0.0.0,your_server_ip,5081
# Request Instant Status
x1
bestpassword Wapn,apn.name,user,pass,0.0.0.0,your_server_ip,5081
# Request Instant Status
x1
B. Remote GPRS Commands
// Reporting: Moving (3001) vs Parked (3002)
+XT:3001,30,5,1 (Report every 30s or 5° turn)
+XT:3002,3600,0,1 (Report every 1 hour when static)
// Output Control (Immobilizer)
+XT:7019,1,1 (Lock / Relay Active)
+XT:7019,1,0 (Unlock / Relay Inactive)
+XT:3001,30,5,1 (Report every 30s or 5° turn)
+XT:3002,3600,0,1 (Report every 1 hour when static)
// Output Control (Immobilizer)
+XT:7019,1,1 (Lock / Relay Active)
+XT:7019,1,0 (Unlock / Relay Inactive)
3. Troubleshooting Guide
A. LED Diagnostic Patterns
| LED Color | State | Meaning / Action Required |
|---|---|---|
| Amber (Cell) | Rapid Flash | Searching for network. Check SIM insertion & Antenna. |
| Amber (Cell) | Solid | GPRS Link Established. Device is communicating. |
| Green (GPS) | Rapid Flash | No GPS Lock. Move device to clear view of sky. |
| Green (GPS) | Slow Blink | 3D GPS Fix attained. Normal operation. |
B. Common Issues & Solutions
- Device not appearing on server: Verify APN settings via SMS. Send
x1to see if the device has a valid IP address. - No Ignition Data: Check White Wire (Pin 5) connection. It must reach >9V to trigger “Ignition ON”.
- Relay/Output not working: Ensure Output 1 (Yellow, Pin 10) is switching to Ground (-). Verify maximum 500mA load.
- Low Battery Alerts: Check Pin 1 (Red) for constant 12V/24V. Many XT models enter “Deep Sleep” if constant power is lost.
- Device not appearing on server: Verify APN settings via SMS. Send
4. 24-Pin Wiring Reference
| Pin | Wire Color | Function |
|---|---|---|
| 1 | Red | Power (+) 6-36V |
| 8 | Black | Ground (-) |
| 5 | White | Ignition Sense (+) |
| 10 | Yellow | Output 1 (Relay) |
| 12 | Blue | Input 1 (Neg Trigger) |
