Xirgo XT Protocol Port 5081 Overview
This guide covers the Xirgo protocol, specifically focusing on the 5081 port used by various XT-series telematics devices.
The Xirgo protocol is a communication standard used by GPS tracking hardware from Xirgo Technologies. It primarily uses UDP or TCP for data transmission, often utilizing ASCII or Binary formats to relay vehicle telemetry.
Key Features of the Protocol:
- Event-Based Reporting: Devices can be configured to send data based on specific triggers like ignition status, harsh braking, or geofence crossings.
- Diagnostic Capabilities: Many XT models support OBD-II data, allowing fleet managers to monitor VIN, fuel levels, and diagnostic trouble codes (DTCs).
- Versatility: The protocol supports a wide range of parameters, from basic GPS coordinates to advanced accelerometer data (XYZ vectors).
- Port 5081: This specific port is widely recognized in tracking platforms.
Supported XT Series Devices
(Protocol Port: 5081)
| Model | Manufacturer | Network / Variant | Protocol Port |
|---|---|---|---|
| XT-2000G | Xirgo | 2G / GSM | 5081 |
| XT-2060G | Xirgo | 2G / GSM | 5081 |
| XT-2050C | Xirgo | CDMA / LTE | 5081 |
| XT-2150 / G / C | Xirgo | Multi-network (GSM/CDMA) | 5081 |
| XT-2160G | Xirgo | 2G / GSM | 5081 |
| XT-3200 | Xirgo | Standard OBD-II | 5081 |
| XT-4500G / 4560G | Xirgo | GPRS / Asset Tracking | 5081 |
| XT-4550C | Xirgo | CDMA Asset Tracking | 5081 |
| XT-4700 / 4760 | Xirgo | 3G / Heavy Duty | 5081 |
| XT-4750C | Xirgo | CDMA Variant | 5081 |
| XT-4860G / 4850C | Xirgo | GPRS / CDMA Hybrid | 5081 |
| XT-5000 / 5060 | Xirgo | Industrial / High Perf | 5081 |
| XT-5050C | Xirgo | CDMA Industrial | 5081 |
| XT-6200 / 6260 | Xirgo | Advanced Telematics | 5081 |
