Homtecs GPS Tracking & Industrial Router Guide
This technical guide details the configuration for Homtecs H20 routers and devices using the 5104 tracking protocol. These industrial-grade devices are designed for robust M2M communication and precision fleet management.
1. Device Comparison: H20 vs. 5104 Series
| Feature | Homtecs H20 Series | 5104 Protocol Devices |
|---|---|---|
| Primary Category | Industrial 4G/LTE Router | High-Speed M2M / 5G Series |
| GPS Capability | Optional Internal GPS Module | Standard Integrated GNSS |
| Interface | 2x LAN, RS232/RS485 Serial | Up to 5x Gigabit LAN, I/O Ports |
| Communication Port | 8888 (Standard) | 5104 (Dedicated Telemetry) |
2. Technical Wiring Diagram
H20/5104 Serial & Power Pinout
VCC (9-36V)
GND (Ground)
ACC (Ignition)
TX (Serial)
RX (Serial)
Note: Always use a multimeter to verify voltage before connecting. Ensure the antenna is placed away from metal shielding for optimal GPS lock.
3. Essential SMS Configuration Commands
Use these commands to authorize your phone and set the tracking server via SMS. Replace 123456 with your device password if changed.
A. Authorization & Admin Setup
admin123456 1234567890
(Sets authorized admin number to 1234567890)
(Sets authorized admin number to 1234567890)
B. Server & Protocol Configuration
To point the device to your tracking platform (Default Port 5104 for the protocol):
SERVER,0,IP_ADDRESS,5104,0#
Example: SERVER,0,123.123.123.123,5104,0#
Example: SERVER,0,123.123.123.123,5104,0#
C. APN Settings (Required for Data)
APN,://apn.com,user,password#
(Configure your carrier’s APN for GPRS/LTE connectivity)
(Configure your carrier’s APN for GPRS/LTE connectivity)
D. Status & Tracking Interval
STATUS# (Check device health/GPS signal)
TIMER,30,300# (Set 30s interval when moving, 300s when stationary)
TIMER,30,300# (Set 30s interval when moving, 300s when stationary)
4. Troubleshooting Connection
- LED Indicators: Red (Power), Blue (GSM/LTE Signal), Green/Yellow (GPS Fix).
- No Data: Verify SIM card balance and that the APN is correctly applied via SMS.
- No GPS Fix: Ensure the device has a clear view of the sky; internal metallic window tints can block signals.
